Apator Ultrimis Neo 16 Water Meter (Ultrasonic)
SKU |
AP-UL_NEO_16 |
incl. 19.0% VAT plus Shipping costs
The Apator Ultrimis NEO16 is an ultrasonic water meter for high-flow residential connections, DN40, with a G2" connection and a 300 mm overall length. It covers a continuous flow rate Q3 of 16 m³/h, with an overload capacity up to Q4 of 20 m³/h, at a start-up flow rate of just 4.5 l/h and a maximum pressure loss of 0.3 bar. MID-approved in the extended measurement range R2000 (SK 24-MI001-SMU076), IP68 protection rating, operating pressure up to 16 bar. Communication in hybrid mode primarily occurs via LoRaWAN (Class A) with automatic fallback to Wireless M-Bus (OMS4/B); configuration and data retrieval are also possible via NFC using the Spidap app. Two lithium AA batteries provide 16 years of battery life; an integrated data logger stores 100 months plus 320 days of historical data.
| Equipment | |
|---|---|
| sensors | water flow |
| antenna | internal |
| Communication | |
| connectivity | LoRaWAN, wMBUS |
| frequency | EU868, EU868 |
| interfaces | NFC |
| activation | OTAA |
| Power supply | |
| power supply | battery, included, not replaceable |
| Certifications | |
| Drinking Water Certificate | ja |
| MID Certificate | and |
| enclosure protection class | IP68 |
| Others | |
| Brand | Apator |
DataSheet_Apator_Ultrimis_EN.pdf
Download
