The Dragino IVS-LN is an industrial-grade LoRaWAN vibration sensor designed for condition monitoring of motors, pumps, fans, and other rotating machinery in accordance with ISO 20816-1. It simultaneously measures RMS acceleration, RMS velocity, vibration frequency, displacement, and surface temperature, and transmits the measured values via LoRaWAN to a cloud platform. The IP68-rated sensor head is designed for temperatures ranging from −40 °C to +80 °C. Configuration via Bluetooth 5.1 or LoRaWAN downlink, OTA firmware updates, DC power supply with a 1,000-mAh backup battery, EU868/US915, and other bands.
| Equipment | |
|---|---|
| sensors | vibration, acceleration / movement |
| antenna | external |
| Communication | |
| connectivity | LoRaWAN |
| frequency | EU868 |
| interfaces | Bluetooth, Downlink |
| activation | OTAA |
| Power supply | |
| power supply | power supply, battery, included, not replaceable |
| battery details | Li-Ion |
| Certifications | |
| enclosure protection class | IP68 |
| Others | |
| Brand | Dragino |
Datasheet_-Dragino-IVS-LN_EN.pdf
Download
