| Equipment | |
|---|---|
| sensors | level |
| antenna | internal |
| Communication | |
| connectivity | LoRaWAN |
| frequency | EU868 |
| activation | OTAA |
| interfaces | App, Bluetooth, Downlink |
| Power supply | |
| power supply | battery, included, not replaceable, power supply |
| battery details | Lithium-Thionylchlorid, nicht aufladbar |
| General | |
| variants | Batterie or Netzteil |
| Certifications | |
| enclosure protection class | IP67 |
| Others | |
| Brand | Macnman |
This industrial-grade sensor is designed for non-contact distance and level measurement in environments such as tanks, reservoirs, silos, waste bins, water systems, chemical storage, and industrial automation.
The sensor offers a measurement range from 3 cm to 450 cm with a resolution of 0.1 cm and an accuracy of ±1% of full scale.
The device features a glass-filled nylon enclosure with an IP65 protection rating, while the sensor itself is rated IP67. It is designed to operate in temperatures ranging from -40°C to +80°C.
Configuration can be performed locally through the Macnman Maya Android App using BLE-based communication or remotely via Over-the-Air (OTA) downlink commands.
Yes, the device supports periodic, event-based, and hybrid reporting modes, allowing users to configure level thresholds for event-triggered data transmissions.
The MacRay LUS X1 BO is a battery-operated model featuring an integrated 8 Ah Lithium battery for remote deployments, whereas the MacRay LUS X1 PO is powered by an external source (9–36 V DC) for continuous monitoring applications.
The integrated Lithium Thionyl Chloride (Li-SOCl2) battery provides approximately 1 year of life at a 5-minute transmission interval, 2 years at a 15-minute interval, and over 4 years at a 60-minute interval.
